Crony Reader

Crony readers are contactless card readers. They have a Red/Green Indicator and a Buzzer for audible and visual feedback. It has a weatherproof IP 65 that makes these readers water-resistant and thus, they are suitable for outdoor and other applications as well.

Available with 2 type of contactless card.

1. 13.56MHz Smart Card

2. 125KHz EM 4100 Card.



Crony Reader	RS485	RS232	USB	Wiegand 34/26	Stand alone
Smart Card 13.56 MHz	CRONY-H-485	CRONY-H-232	CRONY-H-USB	CRONY-H-W34	CRONY-H-M
EM Card 125KHz	CRONY-L-485	CRONY-L-232	CRONY-L-USB	CRONY-L-W34	CRONY-L-M

CRONY-H-485:

This Reader Support contactless 13.56MHz Smart Card and its communication interface is RS485 preventing the reader to make any electrical noise. Its communication protocol allows up to 15 readers on single node (a door controller).

EM lock can be connected to reader. Communication protocol documented in user manual.

Card memory data read make single card to be use in various application.

Download A PDF

Specs:

Interface: RS485 2 wire baud rate 19200 E81

Power: 12V DC current less then 50mA

Card Type: Smart Card 13.56MHz (ISO/IEC 14443 A) Card UID or Memory data can be read.

Visual: Red/Green LED

Audio: Buzzer

EM Lock control Pin up to 500mA

Wire length: 30cm

Dimension:7.7×11.5cm

Weight:82grm

Colour: Off white

Note: Wire length (Reader to Node/controller): upto 500 meter

Application:

Attendance, Access control, Car Parking, Canteen, Gym/Club Member ship.

CRONY-L-485:

This reader support contactless 125KHz EM and its communication interface is RS485.

Communication protocol allow up to 15 readers on single node(controller).

EM lock can be directly connected to reader. Communication protocol documented in user manual.

Download A PDF

Specs:

Interface: RS485 2 wire baud rate 19200 E81

Power: 12V DC current less then 50mA

Card Type: 125KHz EM read 32bit Unique ID of card.

Visual: Red/Green LED

Audio: Buzzer

EM Lock control Pin upto 500mA

Wire length: 30cm

Dimension:7.7×11.5cm

Weight:82grm

Colour: Off white

Note: Wire length (Reader to Node/controller): upto 500 meter

Application:

Attendance, Access control. Car Parking, Canteen, Gym/Club Member ship.

CRONY-L-232:

This reader support contactless 125KHz EM and communication interface is RS232.

Makes it easier to connect with serial port.

Specs:

Interface: RS232 2 wire Tx/Rx baud rate 115200 N81

Power: 12V DC current less then 50mA

Card Type: 125KHz EM read 32bit Unique ID of card.

Visual: Red/Green LED

Audio: Buzzer

Wire length : 30cm

Dimension: 7.7×11.5cm

Weight: 82grm

Colour: Off White

Note: Wire length (Reader to Node/controller): upto 3 meter

Application:

Car Parking, Canteen, or Gym/Club Memberships.

CRONY-H-232:

This reader supports 13.56MHz contactless Smart Card and its communication interface is RS232.

Makes it easier to connect with serial port.

Specs:

Interface: RS232 2 wire Tx/Rx baud rate 115200 N81

Power: 12V DC current less then 50mA

Card Type: 125KHz EM read 32bit Unique ID of card.

Visual: Red/Green LED

Audio: Buzzer

Wire length: 30cm

Dimension: 7.7×11.5cm

Weight: 82grm

Colour: Off White

Note: Wire length (Reader to Node/controller): upto 3 meter

Application:

Car Parking, Canteen, Gym/Club Member ship.

CRONY-L-USB:

This reader supports contactless 125KHz EM and its communication interface is RS232.

Makes it easier to connect with USB port and requires no external power.

USB DRIVER DOWNLOAD

Specs:

Interface: USB virtual Com port baud rate 115200 N81

Power: USB Powered

Card Type: 125KHz EM read 32bit Unique ID of card.

Visual: Red/Green LED

Audio: Buzzer

Wire length : 30cm

Dimension:7.7×11.5cm

Weight: 82grm

Colour: Off White

Application:

Car Parking, Canteen, Gym/Club Member ship.

CRONY-H-USB:

This reader support 13.56MHz contactless Smart Card and its communication interface is RS232.

Makes it easier to connect with USB port and requires no external power.

USB DRIVER DOWNLOAD

Specs:

Interface: USB virtual Com port baud rate 115200 N81

Power: USB Powered

Card Type: 125KHz EM read 32bit Unique ID of card.

Visual: Red/Green LED

Audio: Buzzer

Wire length : 30cm

Dimension:7.7×11.5cm

Weight: 82grm

Colour: Off White

Application:

Car Parking, Canteen, Gym/Club Member ship.

CRONY-L-W34:

This reader supports 125KHz contactless EM Card and its communication interface is wiegand. The Door Access Control Systemscan connect with any wiegand controller which supports wiegand 34 bit protocol. 26 bit is available too, on request.

Specs:

Interface: 2 wire D0 and D1

Power: 12V DC current less then 50mA

Card Type: 125KHz EM read 32bit Unique ID of card.

Visual: Red/Green LED

Audio: Buzzer

Wire length : 1.5 meter

Dimension:7.7×11.5cm

Weight:82grm

Colour: Off White

Application:

Connect to Wiegand Controller.

CRONY-H-W34:

This reader supports 13.56MHz contactless Smart Card and its communication interface is wiegand. It can connect with any wiegand controller which supports wiegand 34 bit protocol. 26 bit is also available on request.

Specs:

Interface: 2 wire D0 and D1

Power: 12V DC current less then 50mA

Card Type: 125KHz EM read 32bit Unique ID of card.

Visual: Red/Green LED

Audio: Buzzer

Wire length : 1.5 meter

Dimension:7.7×11.5cm

Weight:82grm

Colour: off White

Application: Connect to Wiegand Controller.

Demo:-

Crony Wiegand | Door Controller | Access Control

CRONY-L-M

It is an EM 125KHz access control stand alone reader, that can register up to 120 users. It only registers cards to get a door access. Enrolment and disenrollment is easily done through enrol and delete card. Exit switch can be connected to open door from inside. No access log is available.

Specs:

Interface: stand alone (No communication)

Power: 12V DC current less then 50mA

Card Type: 125KHz EM read 32bit Unique ID of card.

Visual: Red/Green LED

Audio: Buzzer

Wire length : 30cm

Dimension:7.7×11.5cm

Weight: 82grm

Colour: Off White

Application:

Store, wear house, cold storage door control.

CRONY-H-M:

This is stand alone Smart Card 13.56MHz access control Reader, can register upto 120 user. Only register card only get access to door. Enrolment and deletion is easily done through enrol and delete card.

Exit switch can be connected to open door from inside. No access log available.

Specs:

Interface: stand alone (No communication)

Power: 12V DC current less then 50mA

Card Type: 125KHz EM read 32bit Unique ID of card.

Visual: Red/Green LED

Audio: Buzzer

Wire length : 30cm

Dimension:7.7×11.5cm

Weight: 82grm

Colour: Off White

Application:

Store, wear house, cold storage door control.
